Hammer Mill Protection Solutions
Hammer Mills in Grain and Feed Processing
Hammer mills are essential machines in the grain, feed, and agricultural industries, widely used for particle size reduction. They grind whole grains, screenings, animal feed ingredients, and related products.
While critical to production, hammer mills are also high-risk equipment for combustible dust explosions. Without the right protection, facilities face safety hazards, equipment damage, and compliance issues with NFPA 660, NFPA 68, and NFPA 69 standards.
Contact us
Why Hammer Mills Pose Explosion Risks
Hammer mills create multiple ignition and explosion hazards due to their design and continuous operation:
- Foreign objects – Stones, tramp metal, and debris can strike the hammers and produce sparks.
- Bearing failures – Continuous 24/7 operation increases the risk of overheating and ignition.
- Airflow systems – Bin vents, cyclones, and baghouses introduce significant explosion isolation challenges.
- Material discharge – Whether product exits through a plenum (gravity) or pneumatic airlift, each method carries unique risks.
- These conditions make hammer mill explosion protection essential to ensure both worker safety and regulatory compliance.
Challenges in Hammer Mill Explosion Protection
- Air intake isolation at feeder housings or louvers is difficult but necessary
- Dust collection systems (baghouses, bin vents, cyclones) are vulnerable ignition and propagation points
- Discharge systems require tailored protection — whether plenum or airlift
Boss Products’ Hammer Mill Protection Solutions
We deliver custom explosion protection systems designed to safeguard hammer mills in milling, feed, and grain processing facilities.
Plenum System Protection (Raptor X)
Active Protection
- Sensors located in the plenum.
- Suppression bottles deployed in plenum.
- Isolation bottles at feeder, dust collection exhaust, or bin vent.
Passive Protection
- Explosion vents or flameless vents on plenum and bin vent.
- Exhaust duct isolation with Vigiflap® valves.
- Explosion isolation rotary valves at plenum discharge.
Airlift System Protection
Active Protection
- Raptor X sensors at mill discharge and filter receiver.
- Raptor X suppression bottle inside hammer mill body and filter receiver.
- Rotary valve isolation in hopper discharge.
- Raptor X isolation bottles on feeder, airlift ducting, and filter receiver.
Passive Protection
- Vigiflap® explosion isolation valves on airlift piping and ducting.
- Spark detection and extinguishing in airlift lines.
- Explosion venting on filter receivers.
- Rotary valve isolation at hopper discharge.
Protect Your Hammer Mill from Dust Explosions
Hammer mills are essential for productivity—but without proper safeguards, they can be one of the most dangerous points in your operation.
- Don’t leave your facility at risk
